Appendices
A-24
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
Changing All Target Device Information including Model Names and
Revisions
1
Right-click one of the connection lines and select Change Node Address from the menu.
2
The Target Device Change Dialog Box is displayed. Select a target device from New device.
Precautions for Correct UsePrecautions for Correct Use
• Changeable target devices are limited to ones that have "OMRON" in the Vendor ID and is an
EDS device of the Communications Adapter in the Device Type.
• To display a device in the list of selectable new target devices, the device must be registered
as the target device in the Toolbox.
3
To apply the same change to other connections, select the Apply the change to other connec-
tions Check Box.
4
Click the OK Button.
