Omron Sysmac NJ-series

3-17
3 System-defined Variables Related to the Built-in EtherNet/IP Port
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
3-2 System-defined Variables
3
*1 With the NJ-series CPU Unit, this variable can be used with the unit version 1.11 or later.
Additional Information
Hierarchical Relationship of System-defined Variables Related to EtherNet/IP Errors in the
NJ-series CPU Unit
The system-defined variables that are related to EtherNet/IP errors have the following hierarchi-
cal relationship. For example, if the value of any of the _EIP_PortErr, _EIP_CipErr, or _EIP_Tc-
pAppErr variables in the second level is TRUE, then the _EIP_ErrSta variable in the first level
also changes to TRUE. Therefore, you can check the values of system-defined variables in a
higher level to see if an error has occurred for a variable in a lower level.
_EIP_DNSSrvErr DNS Server Connec-
tion Error
TRUE: The DNS client failed to connect to
the server (timeout).
FALSE: DNS is not enabled. Or, DNS is
enabled and the connection was
successful.
BOOL TRUE or
FALSE
page 3-49
Level 1 Level 2 Level 3
Variable Name Variable Name Variable Name
_EIP_ErrSta Built-in Ether-
Net/IP Error
_EIP_PortErr Communica-
tions Port Error
_EIP_MacAdr
Err
MAC Address Error
_EIP_LanHwErr Communications Con-
troller Error
_EIP_EtnCfgErr Basic Ethernet Set-
tings Error
_EIP_IPAdrCfg
Err
IP Address Setting
Error
_EIP_IPAdrDupErr IP Address Duplica-
tion Error
_EIP_BootpErr BOOTP Server Error
_EIP_DNSSrvErr DNS Server Connec-
tion Error
_EIP_IPRTblErr
IP Route Table Error
_EIP_CipErr CIP Communi-
cations Error
_EIP_Identity
Err
Identity Error
_EIP_TDLink
CfgErr
Tag Data Link Setting
Error
_EIP_TDLink
OpnErr
Tag Data Link Con-
nection Failed
_EIP_TDLink
Err
Tag Data Link Com-
munications Error
_ EIP_TagAdr
Err
Tag Name Resolution
Error
_EIP_MultiSw
ONErr
Multiple Switches ON
Error
_EIP_TcpAppErr TCP Applica-
tion Communi-
cations Error
_EIP_TcpApp
Cfg
Err
TCP Application Set-
ting Error
_EIP_NTPSrv
Err
NTP Server Connec-
tion Error
Variable name Meaning Function Data type
Range of
values
Reference
