îš„Torque Compensation: C4
* The factory setting will change when the control method is changed. (V/f control factory settings are given.)
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
C4-01
Torque com-
pensation
gain
Sets the torque compensation
gain.
Usually changing this setting
is not necessary.
Adjust it under the following
circumstances:
• When the cable is long
increase the set value.
• When the motor capacity is
smaller than the Inverter
capacity (Max. applicable
motor capacity), increase
the set values.
• When the motor is oscillat-
ing, decrease the set values.
Adjust the torque compensa-
tion gain so that at minimum
speed the output current does
not exceed the Inverter rated
output current.
Do not alter the torque com-
pensation gain from its default
(1.00) when using Open Loop
Vector control.
0.00 to
2.50
1.00 Yes A A A No 215H
4-14
6-38
Torq Comp
Gain
C4-02
Torque com-
pensation
delay time
constant
The torque compensation
delay time is set in ms units.
Usually changing this setting
is not necessary.
Adjust it under the following
circumstances:
• When the motor is oscillat-
ing, increase the set values.
• When the responsiveness of
the motor is low, decrease
the set values.
0 to
10000
200 ms
*
No A A A No 216H
4-14
6-38
Torq Comp
Time
C4-03
Starting
torque com-
pensation
(FWD)
Sets the torque compensation
value at start in FWD direc-
tion
0.0 to
200.0%
0.0% No No No A No 217H 6-38
FTorqCmp
@ Start
C4-04
Starting
torque com-
pensation
(REV)
Sets the torque compensation
value at start in REV direction
-200.0
to 0.0%
0.0% No No No A No 218H 6-38
RTorqCmp
@ Start
C4-05
Starting
torque com-
pensation
time con-
stant
Sets starting torque start-up
time.
When 0 ~ 4 ms is set, it is
operated without filter.
0 to 200 10 ms No No No A No 219H 6-38
TorqCmp-
DelayT
