Omron VARISPEED F7 User Manual

5-40
5
Digital Output Option Card Setup: F5
Param-
eter
Num-
ber
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
F5-01
Channel 1
Output
Selection
Selects the desired multi-function
output for channel 1.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 0 No A A A A 399H -
F5-02
Channel 2
Output
Selection
Selects the desired multi-function
output for channel 2.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 1 No A A A A 39AH -
F5-03
Channel 3
Output
Selection
Selects the desired multi-function
output for channel 3.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 2 No A A A A 39BH -
F5-04
Channel 4
Output
Selection
Selects the desired multi-function
output for channel 4.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 4 No A A A A 39CH -
F5-05
Channel 5
Output
Selection
Selects the desired multi-function
output for channel 5.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 6 No A A A A 39DH -
F5-06
Channel 6
Output
Selection
Selects the desired multi-function
output for channel 6.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 37 No A A A A 39EH -
F5-07
Channel 7
Output
Selection
Selects the desired multi-function
output for channel 7.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 0F No A A A A 39FH -
F5-08
Channel 8
Output
Selection
Selects the desired multi-function
output for channel 8.
This function is enabled when a
digital output card (DO-02 or
DO-08) is used.
0 to 3D 0F No A A A A 3A0H -
F5-09
DO-08 Out-
put Mode
Selection
Sets the output mode.
This function is enabled when the
digital output card (DO-08) is
used.
0:8-Channel Individual Outputs
1:Binary Code Output
2:Outputs according to F5-01 to
08 settings.
0 to 2 0 No A A A A 3A1H -
