Omron ZX Series User Manual

FUN (Function) Mode Section 4-5
130
n Errors when Confirming a Numeric Value
A setting error will occur under the following conditions.
1. When the set value is too large.
2. When the set value is too small.
If an error occurs, the relevant error will be displayed on the sub-display
three times at one-second intervals as shown in the following figure, and
then the previous set value will be displayed.
The error is displayed when the ENT Key is pressed.
1. Errov (Error: Over) 2. ErrUd (Error: Under)

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
