Omron ZX Series User Manual

ZX-L Series Section 3-1
31
3-1 ZX-L Series
The ZX Series are the first of the Smart Sensors from OMRON. In the ZX
Series, ZX-L Laser Sensors include displacement (Reflective) and length-
measuring (through-beam) sensors. The lineup is as follows:
Model Sensing method Function
Sensing center
distance
or sensing width
ZX-LDA11 - Amplifier Unit:
NPN output
-
ZX-LDA41 - Amplifier Unit:
PNP output
-
ZX-LD40 Diffuse reflective
sensor
Sensor Head:
Spot type
40 mm
ZX-LD100 Diffuse reflective
sensor
Sensor Head:
Spot type
100 mm
ZX-LD300 Diffuse reflective
sensor
Sensor Head:
Spot type
300 mm
ZX-LD40L Diffuse reflective
sensor
Sensor Head:
Line type
40 mm
ZX-LD100L Diffuse reflective
sensor
Sensor Head:
Line type
100 mm
ZX-LD300L Diffuse reflective
sensor
Sensor Head:
Line type
300 mm
ZX-LD30V Regular reflective
sensor
Sensor Head:
Spot type
30 mm
ZX-LD30VL Regular reflective
sensor
Sensor Head:
Line type
30 mm
ZX-LT001 Through-beam
sensor
Sensor Head Sensing width:
1-mm dia.
ZX-LT005 Through-beam
sensor
Sensor Head Sensing width:
5mm
ZX-LT010 Through-beam
sensor
Sensor Head Sensing width:
10 mm
ZX-CAL - Calculating Unit -
ZX-XC1A - Extension Cable:
1m
-
ZX-XC4A - Extension Cable:
4m
-
ZX-XC8A - Extension cable:
8m
-
ZX-XC9A - Extension cable:
9m
-

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
