Ratings/Specifications Section 6-1
152
6-1-2 Through-beam Sensor Heads
Note 1. This value is obtained by converting the deviation (±3σ) in the linear
output that results when the Sensor Head is connected to the Ampli-
fier Unit, into the measurement width.
2. For a measurement distance of 0 to 500 mm and an average count of
64. The value is 5 μm for an average count of 32. This is the value that
results when a minimum sensing object blocks the light near the cen-
ter of the 1-mm measurement width.
3. For an average count of 64. The value is 5 μm for an average count of
32.
Item ZX-LT001 ZX-LT005 ZX-LT010
Applicable Amplifier
Units
ZX-LDA11/41
Light source Visible-light semiconductor laser (650-nm wavelength)
Output 0.2 mW max. 0.35 mW max.
Measurement
distance
0 to 500 mm 500 to
2,000 mm
0 to 500 mm
Measurement width 1-mm dia. 1- to 2.5-mm
dia.
5 mm 10 mm
Minimum sensing
object
8-
μm dia.
(opaque)
8- to 50-μm
dia. (opaque)
0.05-mm dia.
(opaque)
0.1-mm dia.
(opaque)
Resolution
(See note 1.)
4
μm
(See note 2.)
---
4
μm (See note 3.)
Temperature
characteristic
0.2% F.S./
°C max.
Ambient
illumination
Incandescent lamp: 10,000 lx max. (on light receiving side)
Ambient
temperature
Operating: 0 to 50
°C, Storage: −25 to 70°C
(with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85%
(with no condensation)
Degree of
protection
IEC 60529, IP40
Cable length Extendable up to 10 m with special extension cable.
Weight
(packed state)
Approx. 220 g
Materials Case: Polyetherimide, Case cover: Polycarbonate,
Unit cover: Glass
Tightening torque 0.3 N·m max.
Accessories Optical axis adjustment seal, sensor head-amplifier connection
cable, instruction sheet
To Next Page
