Through-beam Sensor Heads: RUN Mode Functions
Section 3-6
71
3-6 Through-beam Sensor Heads:
RUN Mode Functions
3-6-1 Sub-display Changes
Items shown on the sub-display can be selected.
The threshold values (HIGH/LOW), voltage value, current value, incident
level, and resolution can be selected.
• Voltage display ëëë The voltage level of the linear output is dis-
played.
• Current display ëëë The current level of the linear output is dis-
played.
• Incident level display ëëë The incident level is displayed (0 to 100)
• Resolution display ëëë The resolution of linear output is displayed.
Display values are provided as reference values. There may be
some discrepancies in actual outputs.
The incident level displayed here is different from the one displayed
on the main display.
POINT
