Hardware Functions
Section 3-2
35
The following values are output according to the setting for non-measure-
ment.
Maximum output voltage: Approximately 5.5 V
Maximum output current: Approximately 23 mA
3-2-2 Outputs
Judgement Outputs
There are three judgement outputs: HIGH, PASS, and LOW.
The following table and illustration show the timing of each output.
l Threshold Values
The threshold values form the boundaries between the HIGH, PASS,
and LOW outputs for the measured value.
There are two threshold values: The HIGH threshold and the LOW
threshold. The threshold values contain hysteresis.
l Hysteresis
The hysteresis (hysteresis width) is the difference between the operating
and releasing values. If the hysteresis is too small, chattering may occur.
If it is too large, releasing may be difficult.
Output
Setting for non-measurement
CLAMP KEEP
Judgement outputs All OFF
The values immediately
before the non-measure-
ment status are kept.
Linear output
Maximum output
value is held.
Main display “- - - - -
Sub-display
The averaging operation is cleared for the reset input. The judge-
ment output response thus may be slower than normal immediately
after releasing the reset input.
POINT
Measured value Judgement outputs
Larger than or equal to HIGH threshold
PASS
HIGH
Smaller than or equal to HIGH threshold Hysteresis
HIGH
PASS
Smaller than or equal to LOW threshold
PASS
LOW
Larger than or equal to LOW threshold Hysteresis
LOW
PASS
Timing of Changes in Judgement Outputs
