Outline of Functions
Section 2-5
26
2-5 Outline of Functions
2-5-1 RUN Mode Displays
Note: The incident level is displayed in Intensity Mode (9999 max.).
2-5-2 T Mode
l Direct threshold value input
l Position teaching
l Two-point teaching
l Automatic teaching
2-5-3 FUN Mode Displays
Main display
Sub-display
Distance
Distance Distance Distance Distance
See note.
Threshold
value
Voltage Current
Incident
level
Resolution
TimerHold
Hysteresis
Number of
average samples
Peak
Bottom
Sample
Peak-to-peak
Self-peak
Self-bottom
Trigger level
OFF-delay
ON-delay
One shot
Time
r time
Scale
.
.
.
.
.
.
.
.
.
.
.
To A
