Outline of Functions Section 2-5
27
Initialization
Special
Functions selected under
Special appear at this level.
Functions connected to Set, diSp, and Etc are
connected to this level when ALL is sele
cted.
Monitor focus
Differentiation
function
Intensity Mode
Display
reverse
ECD
mode
Limited number
of display digi
ts
Settings for
non-measurement
Zero reset memo
ry
Operation
See note 1.
A − B
A + B
.
.
Note 1: Appears only when two Sensor Heads are connected.
Note 2: Appears only when a Through-beam Sensor Head is used.
Note 3: Appears only when a Reflective Sensor Head is used.
Auto-scale
Voltage Gain
Switch
A
See note 2.
See note 3.

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
