Omron ZX Series User Manual

Ratings/Specifications Section 6-1
155
6-1-4 Calculating Unit
Item ZX-CAL
Applicable Amplifier Units ZX-LDA11/41
Current consumption Maximum 12 mA
(supplied from the Smart Sensor Amplifier Unit)
Ambient temperature Operating: 0 to 50
°C, Storage: −15 to 60°C
(with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85%
(with no condensation)
Connection method Connector
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min
Insulation resistance
100 M
Ω (at 500 VDC)
Vibration resistance
(destructive)
10 to 150 Hz, 0.7-mm double amplitude 80 min each in X, Y,
and Z directions
Shock resistance
(destructive)
300 m/s
2
3 times each in six directions (up/down, left/right,
forward/backward)
Materials Display: Acrylic, Case: ABS resin
Weight (packed state) Approx. 50 g

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
