Omron ZX Series - Amplifier Units; Calculating Unit

Names of Sensor Parts Section 1-1
4
1-1-3 Amplifier Units
1-1-4 Calculating Unit
Input cable
(with connector)
Display
area
Controls
Connector
(Cover opens and closes.)
Output cable
The current/voltage switch
for the linear output is on the
bottom.
Connection Indicators:
Light when the Calculating Unit is
connected to Amplifier Units.
Display area
Connector
