Omron ZX Series User Manual

SECTION 2 Outline of Operation
This section describes the overall flow of operation.
2-1 Part Names and Functions ...............................................................20
2-2 Outline of Key Operations.................................................................21
2-3 Procedures for Reflective Sensor Heads ..........................................22
2-3-1 Positioning and Setting Threshold Values...........................22
2-3-2 Setting Various Functions ...................................................22
2-4 Procedures for Through-beam Sensor Heads ..................................24
2-4-1 Positioning and Setting Threshold Values...........................24
2-4-2 Setting Various Functions ...................................................24
2-5 Outline of Functions ..........................................................................26
2-5-1 RUN Mode Displays ............................................................26
2-5-2 T Mode ................................................................................26
2-5-3 FUN Mode Displays ............................................................26

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
