Ratings/Specifications Section 6-1
154
Note 1. The response speed of the linear output is calculated as the measure-
ment period × (average count setting + 1) (with fixed sensitivity).
The response speed of the judgement outputs is calculated as the
measurement period × (average count setting + 1) (with fixed sensitiv-
ity).
2. A Calculating Unit is required.
3. The output can be switched between current output and voltage out-
put using a switch on the bottom of the Amplifier Unit.
4. Setting is possible via the monitor focus function.
5. This function can be set only with a Reflective Sensor Head.
6. This function can be set only with a Through-beam Sensor Head.
Item ZX-LDA11 ZX-LDA41
Indications Operation indicators: High (orange), pass (green), low (yellow), 7-
segment main display (red), 7-segment sub-display (yellow), laser
ON (green), zero reset (green), enable (green)
Power supply voltage
12 to 24 VDC
± 10%, Ripple (p-p): 10% max.
Power consumption Maximum 3.4 W (Sensor connected) (Power supply voltage: 24 V,
Current consumption: Maximum 140 mA)
Ambient temperature Operating: 0
to 50°C, Storage: −15 to 60°C
(with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Insulation resistance 20 M
Ω min. at 500 VDC
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min
Vibration resistance
(destructive)
10 to 150 Hz, 0.7-mm double amplitude 80 min each in X, Y, and Z
directions
Shock resistance
(destructive)
300 m/s
2
3 times each in six directions (up/down, left/right, for-
ward/backward)
Connection method Prewired (standard cable length: 2 m)
Weight (packed state) Approx. 350 g
Materials Case: PBT (polybutylene terephthalate), Cover: Polycabonate
Accessories Instruction sheet
