Optopol SOCT Copernicus + - Page 140

SOCT Copernicus PLUS - Service Manual
140
12. Using a webcam check if out coming light beam falls onto the centre of the calibration cross.
13. If the beam does not fall in the centre, remove upper part of the cover (see: Opening cover).
If beam falls in the centre of the cross, proceed to the point 18.
Dichroic mirror
