Oracle ZFS Storage Appliance

Disk Shelf Hardware Overview
FIGURE 76
Sun Disk Shelf Power Supply Indicators
Figure Legend Figure Legend
1 Cooling fan status indicator 6 Power cord tie wrap
2 AC power status indicator 7 Universal power input connector
3 DC power status indicator 8 Right ejection arm and captive screw latch
4 Power supply status indicator
5 Power on/off switch
Disk Shelf Drive Locations
The following figures show the location of the drives.
284 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
