Oracle ZFS Storage Appliance Service Manual

ZS3-2 Controller Hardware Overview
Slot Mfg Part Number Description Max Note
4-6 7051223 2-port 10Gb Ethernet
Optical NIC
4 Optional
recommended front-
end
4-6 7070006 2-port 10Gb Ethernet
Copper Base-T NIC
4 Optional
recommended front-
end
ZS3-2 NIC/HBA Options - The following table describes the NIC/HBA options for the ZS3-2
controller.
TABLE 28
ZS3-2 Controller NIC/HBA Options
Mktg Part Number Description
SG-SAS6-INT-Z 8-port 6Gb/s SAS-2 internal HBA
SG-XPCIE2FC-QF8-Z 2-port 8Gb FC HBA
7103791 4-port (4x4) SAS-2 6Gb/s external HBA
7101674 2-port 16Gb FC HBA
X1109A-Z 2-port 10GbE SFP+ NIC
X4242A 2-port InfiniBand CX2 HCA
7100477 4-port 1Gb Ethernet Copper UTP NIC
7100488 2-port 10Gb Ethernet Copper Base-T NIC
X2129A XCVR 850NM, 1/10GPS, SFP, short reach
X5562A-Z 10GbE/1GbE SFP+ Transceiver, long reach
ZS3-2 PCIe Riser Configuration - The three risers are labeled Riser 1, Riser 2, and Riser
3. Though similar, the risers are not interchangeable. Riser 1 installs at the left rear of the
chassis, Riser 2 at the center rear, and Riser 3 at the right rear of the chassis. Each riser can
accommodate two PCIe cards:
■
Riser 1 contains slots 1 and 4
■
Riser 2 contains slots 2 and 5
■
Riser 3 contains slots 3 and 6
ZS3-2 Optional Cable Management Arm
The following figure identifies the components of the second-generation cable management arm
(CMA). See the CMA installation instructions.
170 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
