Replacing a 7x20 Fan Module
6.
Slide the replacement drive into the slot until it is fully seated.
7.
Close the latch to lock the drive in place.
8.
Go to the Maintenance > Hardware screen of the BUI. Click the right-arrow icon
for the controller or disk shelf and then click Disk to verify that the online
icon is green for the newly installed drive.
9.
If a fault does not self-clear, see “Repairing Active Problems” on page 37.
Replacing a 7x20 Fan Module
Caution - Operating a controller for over 60 seconds with fans removed reduces the
effectiveness of the cooling system. For this reason, the replacement fan should be unpacked in
advance and ready to insert into the controller chassis as soon as the faulted fan is removed.
Fan modules are hot-swappable and can be removed and installed while the storage controller is
running without affecting other hardware capabilities.
7120 or 7320: The fan modules and status indicators are hidden under a fan door in the 7120
and 7320 storage controllers. Components may differ slightly between the 7120 and 7320,
however service procedures for each are identical. The illustration shows the 7320 controller.
Servicing the 7x20 Controller 175

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
