Disk Shelf Hardware Overview
FIGURE 69
Sun Disk Shelf Back Panel
Figure Legend
1 Power supply modules with built-in fans. Power supply 0 is on the left and power supply 1 is on the right.
2 Removable SAS Interface Module (SIM) Boards. SIM 0 is on the left, and SIM 1 is on the right.
Disk Shelf Indicators
Disk Shelf Front Panel Indicators - The following figures show the front panel indicators.
Servicing the Disk Shelves 277
