ZS3-2 Controller Hardware Overview
ZS3-2 PCIe I/O Cards
ZS3-2 PCIe I/O Options - The following table describes the supported PCIe configuration
options for the ZS3-2 controller. Slots 1 and 2 are reserved for internal and external HBAs, as
shown in the following table. When adding PCIe cards, populate from higher order slots (6)
first toward lower order slots.
Note - Any empty PCIe slots must have a filler panel installed.
TABLE 27
ZS3-2 Controller PCIe Configuration Options
Slot Mfg Part Number Description Max Note
1 7047852 8-port SAS-2
internal HBA
1 Base configuration
2 7067091 4-port (4x4) SAS-2
external HBA
2 Base configuration
3 7067091 4-port (4x4) SAS-2
external HBA
2 Second 4x4-port
SAS-2 external HBA
3 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
3 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
3 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
3 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
3 7051223 2-port 10Gb Ethernet
Optical NIC
4 Optional
recommended front-
end
3 7070006 2-port 10Gb Ethernet
Copper Base-T NIC
4 Optional
recommended front-
end
4-6 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
4-6 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
4-6 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
4-6 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
Servicing the ZS3-2 Controller 169

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
