Oracle ZFS Storage Appliance Service Manual

ZS4-4 Controller Hardware Overview
Figure Legend
5 Temperature sensor TS_ZONE1
(U4507)
11 Temperature sensor TS_ZONE0_A
(U4508)
ZS4-4 Attached Storage
The ZS4-4 standalone and cluster controller configurations allow up to 36 disk shelves,
consisting of up to six chains of one to six DE2-24 disk shelves. Any combination of
disk-only, or disk, log, and read cache devices, can be combined within the chain in
any order. The Sun Disk Shelf is not supported. For more information, see “Disk Shelf
Configurations” on page 286.
Note - Read cache devices must be contained in either the controller or disk shelf, not both.
Related Topics
■
“Connecting to Attached Storage” on page 272
■
“Disk Shelf Hardware Overview” on page 272
■
Oracle ZFS Storage Appliance Cabling Guide
88 Oracle ZFS Storage Appliance Customer Service Manual • July 2016

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
