Oracle ZFS Storage Appliance

7320 Controller Hardware Overview
TABLE 36
7320 Clustered Controllers Configurations
Slot Type Part Number Vendor Part Description Note
0 PCIe 375-3617-01 Intel Niantic DP Optical
10GE NIC
Optional
Recommended
Front-end
0 PCIe 375-3696-01 Mellanox InfiniBand HCA Optional
Recommended
Front-end
0 PCIe 375-3606-03 MHJH29-XTC InfiniBand HCA Optional
Recommended
Front-end
0 PCIe 375-3481-01 Intel
EXPI9404PT
QP Copper NIC Optional
Recommended
Front-end
0 PCIe 371-4325-01 QLogic 8Gb DP FC
HBA
Optional
FC Target
or Initiator
(Backup)
1 PCIe 542-0298-01 Sun Fishworks
Cluster Card 2
Cluster Base
Configuration
2 PCIe 375-3609-03 Sun Thebe External SAS
HBA
Cluster Base
Configuration
7320 Front and Back Panel Components
7320 Front Panel Components - The following figure and legend identify the front panel
LEDs.
