Oracle ZFS Storage Appliance Service Manual

7320 Controller Hardware Overview
Slot Type Part Number Vendor Part Description Note
0 PCIe 375-3696-01 Mellanox InfiniBand HCA Optional
Recommended
Front-end
0 PCIe 375-3606-03 MHJH29-XTC InfiniBand HCA Optional
Recommended
Front-end
0 PCIe 375-3481-01 Intel
EXPI9404PT
QP Copper NIC Optional
Recommended
Front-end
0 PCIe 371-4325-01 QLogic 8Gb DP FC
HBA
Optional
FC Target
or Initiator
(Backup)
1 PCIe 375-3617-01 Intel Niantic DP Optical
10GE NIC
Optional
Recommended
Front-end
1 PCIe 375-3696-01 Mellanox InfiniBand HCA Optional
Recommended
Front-end
1 PCIe 375-3606-03 MHJH29-XTC InfiniBand HCA Optional
Recommended
Front-end
1 PCIe 375-3481-01 Intel
EXPI9404PT
QP Copper NIC Optional
Recommended
Front-end
1 PCIe 371-4325-01 QLogic 8Gb DP FC
HBA
Optional
FC Target
or Initiator
(Backup)
2 PCIe 375-3609-03 Sun Thebe External SAS
HBA
Base
Configuration
7320 Cluster Configurations - The 7320 cluster base configuration is 96GB RAM, 2x2.4GHz
Quad-Core processors, one external SAS HBA, and four 10/100/1000 Ethernet ports, and a
Cluster card. The Sun Storage 7420C Cluster Upgrade Kit (XOPT 594-4680-01) contains two
cluster cards with cables for converting two 7320 or two 7420 controllers to a cluster.
The following options are available for clustered storage controllers.
Note - When you cluster a 7320, you must identically configure the cards in both of the
clustered storage controllers, and you must identically configure all optional NIC/HBA cards
used in the clustered storage controllers in both chassis.
Servicing the 7x20 Controller 231

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
