Replacing a 7x20 Fan Module

Caution - The storage controller might overheat and shut down if the door is left open for more

than 60 seconds.

7420: The following illustration shows the fan modules in the 7420 storage controller.

176 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
