Installation Instructions Intelligent Controller
Please Read Before Starting
This controller must be installed by the sales dealer or installer.
These instructions are all you need for most installation sites
and maintenance conditions. If you require help for a special
problem, contact our sales/service outlet or your certied dealer
for additional instructions.
WARNING
This symbol refers to a hazard or unsafe
practice which can result in severe personal
injury or death.
CAUTION
This symbol refers to a hazard or unsafe
practice which can result in personal injury
or product or property damage.
z We assume no responsibility for accidents or damages
resulting from methods other than those described in the
installation instructions or methods without using specied
parts. Malfunctions that occurred due to the unauthorised
installation methods are not covered by the product warranty.
z This controller shall be installed in accordance with National
Wiring Regulations.
z After the installation is complete, perform test operation to
conrm that no abnormality is present.
z
Read the installation instructions of devices to be connected as well.
z When relocating or repairing this controller, provide the
Installation Instructions to the servicing personnel.
WARNING
ELECTRICAL SHOCK CAN CAUSE
SEVERE PERSONAL INJURY OR DEATH.
ONLY A QUALIFIED, EXPERIENCED
ELECTRICIAN SHOULD ATTEMPT TO
WIRE THIS SYSTEM.
z
Highly dangerous electrical voltages are used in
this system. Carefully refer to the wiring diagram
and these instructions when wiring.
Improper connections and inadequate grounding
can cause
accidental injury or death
.
z
This controller is strongly recommended to be
installed with Earth Leakage Circuit Breaker
(ELCB) or Residual Current Device (RCD).
Otherwise, it may cause electrical shock
and re in case of equipment breakdown or
insulation breakdown.
Earth Leakage Circuit Breaker (ELCB) must be
incorporated in the xed wiring in accordance
with the wiring regulations. The Earth Leakage
Circuit Breaker (ELCB) must be an approved
10 A, having a contact separation by 3 mm in
all poles.
z Provide a power outlet to be used exclusively
for this controller.
z Turn off the circuit breaker of the controllers
before installation.
z
Do not supply power to the controller until all
wiring is completed or reconnected and checked.
z Fix the power supply wiring securely with the
clamper so that the power supply terminal
board is free of tension (external force) when
pulled. Loose connection of the terminal
board may cause re.
z
To prevent possible hazards from insulation
failure, the controller must be grounded.
z
Select an installation location which is rigid and
strong enough to support or hold the controller,
and select a location for easy maintenance.
z This product must not be modied or
disassembled under any circumstances.
Modied or disassembled controller may
cause re, electric shock or injury.
z
Do not clean inside the controller by users.
Engage authorized dealer or specialist for cleaning.
z Do not operate with wet hands.
CAUTION
z Ground yourself to discharge static electricity
before performing any wiring.
z
Do not use the controller at the following locations.
• Areas where leakage of ammable gas may
be expected
• Places where large amounts of oil mist exist
•
Locations where external air may enter the room
directly (This may cause “condensation”)
• Locations where high-frequency emissions
are generated
•
Locations where voltage uctuation frequently occurs
z Do not wash with water.
NOTICE
The English text is the original instructions. Other languages are
translation of the original instructions.
Safety Precautions
Model No. CZ-256ESMC3
Dimensions
[H × W × D]
240 × 280 × (20 + 65) mm
Weight 2.7 kg
Temperature/
Humidity range
0 °C to 40 °C / 20 % to 80 %
(no condensation) Indoor use only.
Rated voltage/
Rated frequency
Single phase 100-240 V ~ 50/60 Hz
Power consumption
Max. 20 W
Clock
Precision
± 30 seconds/month (at normal temperature 25 ˚C)
* Adjust periodically.
Holding
time
100 days (at normal temperature 25 °C with full charge)
* Approx. 8 hours are required for full charge.
Number of
connectable
units per link
*1
Up to 100 units of the combined total of the
following
• Indoor unit - Up to 64 units*
2
• Outdoor unit - Up to 30 units
•
Central control device - Up to 10 units
Specications
*1: The maximum number of connectable units is shown below.
• When using only this unit: 128 indoor units and 60 outdoor units
• When connecting a Communication Adaptor: 256 indoor units and 120 outdoor units
*2: The number of indoor units includes the
Interface Adaptor.
