Replacement of SD card, and operation procedure at time of failure
Various procedures
Replacement of SD card, and operation procedure at time of failure
The operation procedure is different depending on the type of SD device and SD card. Always replace the SD
card according to the replacement procedure of the SD card you want to replace. If you perform SD card copy,
database switch operation, etc. without following the operation procedure, it will cause data loss or damage,
which will not be possible to recover from, so please observe caution.
●●● Caution ●●● (Cause of malfunction!)
· Do not insert or remove the SD card while working or with the power turned on.
· Be sure to turn off the power before each time the SD card is replaced (or switched between slots 1 and 2)
during operation.
· Do not forcibly remove the USB memory device except if instructed to do so on the screen. Doing so may
cause data corruption.
If you have started the Intelligent Controller normally without removing the USB memory device, please
push down on the USB removal button on the normal screen and remove it.
● When replacing the SD card, turn off the power of the main unit, set the DIP switch (SW7) 3 on the main board
to ON, and turn on the main unit. To return to the normal screen, turn off the main unit, set the DIP switch (SW7)
3 to OFF, and turn on the main unit.
When starting up with SW7 3 set to ON, the following screen starts up.
Normal mode SD card exchange mode
