Display and settings for the communication adaptor board Various procedures
Display and settings for the communication adaptor board
1. Overview
1
Communication adaptor board
•
It is possible to display/set using the four keys (HOME/UP/DOWN/SET), 6-digit 7-segment and 2 LEDs
(red/green).
HOME key
Power supply
terminal strip
Power switch Signal terminal strip
7-segment numerical display
LED
UP/DOWN/SET
keys
Terminating resistance
plug for communication
adaptor control wiring
2
7-segment numerical display
Contents Display Contents Display Contents Display Contents Display
