20
Preparations before changing settings
Preparation
Initial settings
The initial settings are those items that require setting after the unit is installed so that the system operates
normally.
The unit will operate normally if you make settings according to the following ow for the type of operation
intended.
: Settings required. : Settings may be required. : Settings not required.
Step Category step Setting Screen menu names
Reference
page
Operation
Air
conditioning
operations
only
Distribution rate
display only
Quantity used,
charges display
Time Load Time Load
1 Date settings
Setting the current date
and time
Date settings
178
2
Composition
loading
Conrming the connection
conguration
Check conguration
—
3 Unit related
Central address*
1
I/D unit settings 141
Name of the indoor units I/D unit settings 141
Distribution group I/D unit settings 141
Area group I/D unit settings
141
*
2
Control group I/D unit settings
141
Not batch, not managed I/D unit settings
141
Name of the outdoor units O/D unit settings
145
Local remote controller
prohibition setting
A/C communication settings
184
4 Group related
Name of the area group Area group name settings
153
*
2
Name of the distribution
group
Distribution group settings
155
Name of the schedule group Schedule group name settings
151
5
Pulse meter
related
Association with the
distribution group
Pulse meter settings
158
Type of pulse meter
(electricity/gas), multiplying
factor (number of pulse
units)
Pulse meter settings
158
Name of the pulse meter Pulse meter settings
158
6
Distribution
related
Distribution modes (time/
load)
Distribution mode settings
160
Power distribution
calculation target*
3
Distribution mode settings
160
Energy saving distribution
setting
Distribution mode settings
160
*
4
*
4
Distribution of gas for power
generation
Distribution mode settings
160
*
5
*
5
Setting the monthly cut-off
days
Calendr sttngs for distr calc
148
*
6
Setting the regular hour
range
Calendr sttngs for distr calc
148
Setting specied days Calendr sttngs for distr calc
148
Currency for electricity or
gas charges*
7
Distribution Ratio settings
161
Setting the capacity of the
indoor units*
8
I/D unit settings
141
Setting the capacity of the
electric heater*
9
I/D unit settings
141
7
Scheduling
related
Schedule for a single day Schedule setting
43
Allocating a schedule to a
calendar
Calendar
49
Schedule group I/D unit settings
141
8 Event control
Input point (names and
conditions)*
10
Event control
162
Output point (names and
operation)*
11
Event control
162
21
Preparations before changing settings
Preparation
Initial settings
Step Category step Setting Screen menu names
Reference
page
Operation
Air
conditioning
operations
only
Distribution rate
display only
Quantity used,
charges display
Time Load Time Load
9 Network related*
12
IP address, net mask,
DHCP, etc.
Network settings
123
Setting to send alarm mails Email settings
168
User ID, password,
privileges
Web user settings
125
10
Intelligent
controller related
Buzzer volume Display/Volume settings
173
Brightness of the back light Display/Volume settings
173
Auto logout time Display/Volume settings
173
Identication number Initialize
176
Initialise the days
accumulated data*
13
Initialize
176
*1 Attention needs to be paid to administration divisions when devices such as systems controllers are to be used in conjunction with this unit.
*2 Settings required when area administration is to be performed.
*3 Select the object of calculations for electricity distributing from the following:
Operating hours Select when consideration is to be paid to the electricity for the indoor units. The electricity for outdoor units and indoor units are both
loaded into this unit and distributed.
Thermostat on times Select when no consideration is to be paid to the electricity for the indoor units. The electricity for outdoor units only is loaded into this
unit and distributed.
*4 If the air conditioning units included in the system are multi-function types supporting simultaneous heating and cooling or ice thermal storage models, settings
are required.
*5 Settings are required only when units are GHP with generators.
*6 Settings are required when only the accumulation operating time is to be managed.
*7 This must be set if you want to display charges.
*8 This only needs to be set for interface adaptors. (→“Interface adaptors (sold separately)” (P.198))
*9 This is used when calculating load distributing.
*10 Set items such as batch startup and stopping from external input.
*11 Set items such as batch alarm output to external devices.
*12 Required when logging in through a network device to operate and monitor.
*13 Clears the data calculated from test operation of the air conditioning units before hand over.
