3 Laser Marker NAVI smart basics
3.4 “Monitor” screen
In this screen, you can monitor the operation status of the laser marking system during
remote mode or RUN mode.
You can do the following:
• Check the marking image.
• Check the marking settings (only enabled parameters are displayed).
• Check the ON or OFF status of I/O terminals.
• Check data for on-the-fly marking.
3.5 “Maintenance” screen
This screen is used for the maintenance of the laser marking system.
You can do the following:
• Check the operating data.
• Check the error log.
• Check the communication command history.
• Start laser radiation to measure the laser power (commercial power meter required).
• Simulate output operation.
3.6 “Data management” screen
This screen lists all files that are currently saved on the laser marking system, including
marking files, graphic files and font files.
You can do the following:
• Add or delete a marking file, graphic file, or font file.
• Copy a backup file from the laser marking system.
• Save a backup file or restore it to the laser marking system.
• Change the name of a marking file.
ME-NAVIS2-OP-1 35
