Chapter 4 Settings — [PICTURE] menu
104 - ENGLISH
f The selection item for the DIGITAL LINK input can be selected when the optional DIGITAL LINK Terminal Board (Model No.: TY-SB01DL) is
installed in the slot.
f The selection item for the PressIT input can be selected when the optional Wireless Presentation System Receiver Board (Model No.:
TY-SB01WP) is installed in the slot.
f The selection item for the SLOT input can be selected when the Function Board from other manufacturers is installed in the slot.
f For the SDI input and the SDI OPT input, the signal format can be set in detail in the [DISPLAY OPTION] menu → [SLOT IN].
[DEFAULT PICTURE MODE]
Set the picture mode to be applied when a new signal is input. The setting in the [PICTURE] menu → [PICTURE
MODE] will switch according to the setting.
1) Press as to select [DEFAULT PICTURE MODE].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO]
Set [PICTURE MODE] to [GRAPHIC] when a computer signal is input or [STANDARD] when a video
signal is input.
[STANDARD] Set [PICTURE MODE] to [STANDARD].
[CINEMA] Set [PICTURE MODE] to [CINEMA].
[NATURAL] Set [PICTURE MODE] to [NATURAL].
[REC709] Set [PICTURE MODE] to [REC709].
[DICOM SIM.] Set [PICTURE MODE] to [DICOM SIM.].
[DYNAMIC] Set [PICTURE MODE] to [DYNAMIC].
[GRAPHIC] Set [PICTURE MODE] to [GRAPHIC].
Note
f The following are the conditions where the setting in the [PICTURE] menu → [PICTURE MODE] is switched to the picture mode set in
[DEFAULT PICTURE MODE].
g When a new signal is input
g When the deleted signal is input again after the registered signal has been deleted
g When the <DEFAULT> button is pressed while the [PICTURE] menu → [PICTURE MODE] is selected
g When there is no input signal
f [DEFAULT PICTURE MODE] cannot be set when the [PROJECTOR SETUP] menu → [STORE TYPE] is set to [SHARED].
sRGB-compliant video
sRGB is an international standard (IEC61966‑2‑1) for color reproduction dened by IEC (International
Electrotechnical Commission).
Set according to the following steps to reproduce more faithful, sRGB compliant colors.
1) Set [COLOR MATCHING] to [OFF].
f Refer to [COLOR MATCHING] (x page 120).
2) Display the [PICTURE] menu.
f Refer to “[PICTURE] menu” (x page 95).
3) Press as to select [PICTURE MODE].
4) Press qw to set [REC709].
5) Press as to select [GAMMA].
6) Press qw or the <ENTER> button.
f The [GAMMA] individual adjustment screen is displayed.
7) Press qw to select [2.2].
8) Press as to select [COLOR].
9) Press the <DEFAULT> button on the remote control to set the factory default setting.
10) Follow Steps 8) - 9) to set [TINT], [COLOR TEMPERATURE], [WHITE GAIN], and [SYSTEM DAYLIGHT
VIEW] to the factory default settings.
Note
f sRGB is available for RGB signal input only.
