Chapter 4 Settings — [PICTURE] menu
ENGLISH - 95
[PICTURE] menu
On the menu screen, select [PICTURE] from the main menu, and select an item from the sub-menu.
Refer to “Navigating through the menu” (x page 89) for the operation of the menu screen.
Note
f On the [PICTURE] menu screen (without selecting [DEFAULT PICTURE MODE]), you can set [STORE TYPE] on the [OPTION] screen
displayed by pressing the <INPUT MENU> button on the remote control or control panel.
f The [STORE TYPE] setting item in [OPTION] screen is common with the menu item of the [PROJECTOR SETUP] menu → [STORE TYPE]
(x page 177).
[PICTURE MODE]
You can switch to the desired picture mode suitable for the image source and the environment in which the
projector is used.
1) Press as to select [PICTURE MODE].
2) Press qw.
f The [PICTURE MODE] individual adjustment screen is displayed.
3) Press qw to switch the item.
f The items will switch each time you press the button.
[STANDARD]
The image becomes suitable for video signals in general.
[CINEMA]
The image becomes suitable for movie contents.
[NATURAL]
The image becomes suitable for using in a relatively dark environment.
[REC709]
The image becomes Rec.709 compliant when the setting other than [PICTURE MODE] is set to the
factory default.
[DICOM SIM.]
The image becomes similar to that of DICOM Part 14 Grayscale Standard.
[DYNAMIC]
The image becomes suitable for use in bright areas.
[GRAPHIC]
The image becomes suitable for computer signal input.
Note
f Rec.709 is an abbreviation of “ITU-R Recommendation BT.709” and is a color standard of high-vision broadcasting.
f DICOM is an abbreviation of “Digital Imaging and COmmunication in Medicine” and is a standard for medical imaging devices. Although the
DICOM name is used, the projector is not a medical device, and should not be used for purposes such as diagnosis of display images.
f If the <ENTER> button is pressed while [PICTURE MODE] is selected, the adjustment condition that is currently set can be saved as a
specied value of the selected picture mode. The data of all items except [SYSTEM SELECTOR] and [DEFAULT PICTURE MODE] in the
[PICTURE] menu are saved.
f If the [PICTURE] menu → [DEFAULT PICTURE MODE] is set to [AUTO], [GRAPHIC] is automatically selected when a new computer signal
is input, and [STANDARD] is automatically selected when a new video signal is input. If the [PICTURE] menu → [DEFAULT PICTURE
MODE] is set to anything other than [AUTO], the picture mode set in [DEFAULT PICTURE MODE] is selected when a new signal is input.
[CONTRAST]
You can adjust the contrast of the colors.
1) Press as to select [CONTRAST].
2) Press qw or the <ENTER> button.
f The [CONTRAST] individual adjustment screen is displayed.
3) Press qw to adjust the level.
Operation Adjustment Range of adjustment
Press w.
The screen becomes brighter.
-
31 - +31
Press q.
The screen becomes darker.
Attention
f Adjust the [PICTURE] menu → [BRIGHTNESS] rst when you need to adjust the black level.
To Next Page
