Chapter 4 Settings — [DISPLAY OPTION] menu
132 - ENGLISH
Setting [SYSTEM SELECTOR] in [SLOT IN] (SDI input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SYSTEM SELECTOR].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO]
Automatically selects [RGB], [YP
B
P
R
4:4:4], or [YP
B
P
R
4:2:2].
[RGB]
Fixes to [RGB].
[YP
B
P
R
4:4:4]
Fixes to [YP
B
P
R
4:4:4].
[YP
B
P
R
4:2:2]
Fixes to [YP
B
P
R
4:2:2].
Setting [BIT DEPTH] in [SLOT IN] (SDI input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [BIT DEPTH].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO]
Automatically selects [12-bit] or [10-bit].
[12-bit]
Fixes to [12-bit].
[10-bit]
Fixes to [10-bit].
When the optional Function Board for 12G-SDI Optical (Model No.: TY-SB01FB) is installed
Set this item according to the input and output signals when this Function Board is installed in the slot.
Setting [SDI OPT OUT] in [SLOT IN] (OPT input)
Set whether or not to output the signal from the <SDI OPT OUT> terminal.
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SDI OPT OUT].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[ENABLE]
Select this item when the input signal to the <SDI OPT 1 IN> terminal or the <SDI OPT 2 IN> terminal
that is selected for input is to be output from the <SDI OPT OUT> terminal.
[DISABLE]
Does not output the signal from the <SDI OPT OUT> terminal.
Setting [SIGNAL LEVEL] in [SLOT IN] (OPT input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
