Chapter 7 Appendix — Specications
ENGLISH - 295
Acoustic noise
*1
42 dB
when [OPERATING MODE] is set to [NORMAL] or
[ECO]
38 dB when [OPERATING MODE] is set to [QUIET]
Operating
environment
Operating temperature
0 °C (32 °F) to 45 °C (113 °F)
*2*3*4
Operating humidity
10 % to 80 % (no condensation)
Operation position
[FLOOR/CEILING], [FRONT/REAR]
Power requirements
100 V - 240 V ~ (100 V - 240 V alternating current), 50 Hz/60 Hz
Rated current
11.5 A - 4.7 A
Maximum power consumption
PT-REQ15, PT-REQ15L
1 140 W
PT-REZ15, PT-REZ15L
1 090 W
Standby mode power consumption
Approx. 12 W
When [STANDBY MODE] is set to [NORMAL]
f [QUICK STARTUP] function is disabled
f no Function Board attatched
f <DC OUT> terminal is not in use
Approx. 0.5 W when [STANDBY MODE] is set to [ECO]
Standard outside
dimensions
Width
498 mm (19-19/32") (excluding protrusions)
Height
212 mm (8-11/32") (with the feet at shortest position)
196 mm (7-23/32") (excluding the feet and protrusions)
Depth
PT-REQ15, PT-REZ15
648 mm (25-1/2") (excluding protrusions, including
standard zoom lens)
PT-REQ15L, PT-REZ15L
538 mm (21-3/16") (excluding protrusions and optional
lens)
Weight
*5
PT-REQ15, PT-REZ15
Approx. 28.7 k] (63.3 lbs.) (including standard zoom
lens)
PT-REQ15L, PT-REZ15L
Approx. 27.0 k] (59.5 lbs.) (excluding the optional lens)
Outer case
Materials
Molded plastic
Color
Black
Power cord length
3.0 m (118-1/8")
Laser
Classication
Laser Class
Class 1 (IEC 60825-1:2014)
Risk Group
Risk group 3 (IEC 62471-5:2015)
Wireless LAN
*6
Compliance standards
IEEE802.11b/g/n
Transmission method
DSSS, OFDM
Frequency range
(Channel)
2 412 MHz to 2 462 MHz (1 to 11ch)
Data transfer speed
(Standard value)
IEEE802.11n Maximum 144 Mbps
IEEE802.11g Maximum 54 Mbps
IEEE802.11b Maximum 11 Mbps
Encryption method
WPA2-PSK (AES)
Remote control
Power requirements
DC 3 V (AAA/R03/LR03 battery x 2)
Operating range
Within approx. 30 m (98'5") (when operated directly in front of signal receiver)
Weight
102 ] (3.6 ozs.) (including batteries)
Outside dimensions
Width: 48 mm (1-7/8"), Height: 145 mm (5-23/32"), Depth: 27 mm (1-1/16")
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118:2020 international standards.
*2 The operating environment temperature should be between 0 °C (32 °F) and 40 °C (104 °F) if the projector is used at an altitude between 1 400 m
(4 593') and 4 200 m (13 780') above sea level. Note that altitude of 4 200 m (13 780') above sea level is the maximum height that the performance
of this projector is guaranteed.
*3 The operating environment temperature should be between 0 °C (32 °F) and 40 °C (104 °F) when the optional Wireless Module (Model No.:
AJ-WM50 Series) is attached.
*4 When the operating environment temperature exceeds the following value, the light output may be reduced to protect the projector.
f When using the projector at an altitude lower than 1 400 m (4 593') above sea level: 35 °C (95 °F)
f When using the projector at an altitude between 1 400 m (4 593') and 2 700 m (8 858') above sea level: 30 °C (86 °F)
f When using the projector at an altitude between 2 700 m (8 858') and 4 200 m (13 780') above sea level: 25 °C (77 °F)
*5 Average value. Weight varies for each product.
*6 To use the wireless LAN function with the projector, it is necessary to attach the optional Wireless Module (Model No.: AJ-WM50 Series).
Note
f The model numbers of accessories and optional accessories are subject to change without prior notice.
