Chapter 7 Appendix — Specications
ENGLISH - 301
List of single link SDI compatible signals
The following table species the single link SDI signals that the projector can project.
This is supported when the optional 12G-SDI Terminal Board (Model No.: TY-SB01QS) or the optional Function
Board for 12G-SDI Optical (Model No.: TY-SB01FB) is installed in the slot.
f The content of the 4K division column is as follows.
g IL: Interleave (transmission format of 2-Sample Interleave Division)
f The content of the signal type column is as follows.
g V: Video signal
Signal
type
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
4K
division
Format
Color
format
Sampling
Horizontal
(kHz)
Vertical
(Hz)
V 720/60p
*1
1 280 x 720 45.0 60.0
*2
74.3 ― HD-SDI YP
B
P
R
4:2:2 10bit
720/50p
*1
1 280 x 720 37.5 50.0 74.3 ― HD-SDI YP
B
P
R
4:2:2 10bit
1080/60i
1 920 x 1 080i 33.8 60.0
*2
74.3 ― HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080i 33.8 60.0
*2
74.3 ― 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080i 33.8 60.0
*2
74.3 ― 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080i 33.8 60.0
*2
74.3 ― 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080i 33.8 60.0
*2
74.3 ― 3G-SDI Level-B RGB 4:4:4 12bit
1080/50i
1 920 x 1 080i 28.1 50.0 74.3 ― HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080i 28.1 50.0 74.3 ― 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080i 28.1 50.0 74.3 ― 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080i 28.1 50.0 74.3 ― 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080i 28.1 50.0 74.3 ― 3G-SDI Level-B RGB 4:4:4 12bit
1080/24p
1 920 x 1 080 27.0 24.0
*2
74.3 ― HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080 27.0 24.0
*2
74.3 ― 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080 27.0 24.0
*2
74.3 ― 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080 27.0 24.0
*2
74.3 ― 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080 27.0 24.0
*2
74.3 ― 3G-SDI Level-B RGB 4:4:4 12bit
1080/24sF
*1
1 920 x 1 080i 27.0 48.0
*2
74.3 ― HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080i 27.0 48.0
*2
74.3 ― 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080i 27.0 48.0
*2
74.3 ― 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080i 27.0 48.0
*2
74.3 ― 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080i 27.0 48.0
*2
74.3 ― 3G-SDI Level-B RGB 4:4:4 12bit
1080/25p
1 920 x 1 080 28.1 25.0 74.3 ― HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080 28.1 25.0 74.3 ― 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080 28.1 25.0 74.3 ― 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080 28.1 25.0 74.3 ― 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080 28.1 25.0 74.3 ― 3G-SDI Level-B RGB 4:4:4 12bit
