Chapter 7 Appendix — Specications
ENGLISH - 307
Signal
type
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
4K
division
Format
Color
format
Sampling
Horizontal
(kHz)
Vertical
(Hz)
V
4096 x 2160/30p
4 096 x 2 160 67.5 30.0
*1
297.0 SQ HD-SDI YP
B
P
R
4:2:2 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-A YP
B
P
R
4:2:2 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-A YP
B
P
R
4:2:2 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-B YP
B
P
R
4:2:2 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-B YP
B
P
R
4:2:2 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-A YP
B
P
R
4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-A YP
B
P
R
4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-B YP
B
P
R
4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-B YP
B
P
R
4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-A YP
B
P
R
4:4:4 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-A YP
B
P
R
4:4:4 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-B YP
B
P
R
4:4:4 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-B YP
B
P
R
4:4:4 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-A RGB 4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-A RGB 4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-B RGB 4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-B RGB 4:4:4 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-A RGB 4:4:4 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-A RGB 4:4:4 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 SQ 3G-SDI Level-B RGB 4:4:4 12bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL 3G-SDI Level-B RGB 4:4:4 12bit
4096 x 2160/60p
4 096 x 2 160 135.0 60.0
*1
594.0 SQ 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
4 096 x 2 160 135.0 60.0
*1
594.0 IL 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
4 096 x 2 160 135.0 60.0
*1
594.0 SQ 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
4 096 x 2 160 135.0 60.0
*1
594.0 IL 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
4096 x 2160/50p
4 096 x 2 160 112.5 50.0 594.0 SQ 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
4 096 x 2 160 112.5 50.0 594.0 IL 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
4 096 x 2 160 112.5 50.0 594.0 SQ 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
4 096 x 2 160 112.5 50.0 594.0 IL 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
*1 The signal with 1/1.001x vertical scanning frequency is also supported.
