Chapter 2 Getting Started — Setting up
ENGLISH - 47
r When the image aspect ratio is 21:9
(Unit: m)
Lens type Zoom Lens
Projection lens Model No. ET-C1U100
*2
ET-C1W300 ET-C1W400 ET-C1W500
Standard zoom
lens/ ET-C1S600
ET-C1T700
Throw ratio
*1
0.309 - 0.331:1 0.551 - 0.691:1 0.680 - 0.952:1 0.942 - 1.39:1 1.36 - 2.10:1 2.07 - 3.38:1
Projected image size Projection distance (L)
Diagonal
(SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.78 (70") 0.691 1.638 ― ― 0.89 1.12 1.10 1.55 1.53 2.27 2.21 3.43 3.37 5.52
2.03 (80") 0.790 1.872 ― ― 1.02 1.29 1.26 1.77 1.76 2.60 2.54 3.92 3.86 6.32
2.29 (90") 0.889 2.106 ― ― 1.16 1.45 1.43 2.00 1.98 2.93 2.86 4.42 4.36 7.12
2.54 (100") 0.987 2.340 0.71 0.76 1.29 1.62 1.59 2.23 2.20 3.26 3.19 4.92 4.85 7.92
3.05 (120") 1.185 2.808 0.86 0.92 1.55 1.95 1.92 2.68 2.65 3.92 3.84 5.92 5.84 9.52
3.81 (150") 1.481 3.510 1.08 1.16 1.95 2.45 2.41 3.36 3.32 4.91 4.82 7.41 7.32 11.92
5.08 (200") 1.975 4.681 1.46 1.56 2.61 3.27 3.22 4.49 4.44 6.56 6.45 9.90 9.80 15.91
6.35 (250") 2.468 5.851 1.83 1.96 3.27 4.10 4.04 5.63 5.56 8.21 8.07 12.40 12.27 19.91
7.62 (300") 2.962 7.021 2.20 2.36 3.93 4.93 4.85 6.76 6.68 9.86 9.70 14.89 14.74 23.91
8.89 (350") 3.456 8.191 2.57 2.76 4.59 5.76 5.67 7.89 7.80 11.51 11.33 17.38 17.21 27.91
10.16 (400") 3.949 9.361 2.95 3.16 5.25 6.58 6.49 9.03 8.92 13.16 12.96 19.87 19.68 31.91
12.70 (500") 4.936 11.701 3.69 3.96 6.57 8.24 8.12 11.29 11.16 16.46 16.22 24.85 24.63 39.91
15.24 (600") 5.924 14.042 4.44 4.76 7.89 9.89 9.75 13.56 13.40 19.76 19.47 29.84 29.57 47.91
17.78 (700") 6.911 16.382 5.18 5.56 9.22 11.55 11.38 15.83 15.64 23.06 22.73 34.82 34.52 55.91
20.32 (800") 7.898 18.722 5.93 6.36 10.54 13.21 13.01 18.09 17.88 26.36 25.98 39.80 39.46 63.91
22.86 (900") 8.886 21.062 6.67 7.16 11.86 14.86 14.65 20.36 20.12 29.66 29.24 44.79 44.40 71.91
25.40 (1000") 9.873 23.403 7.42 7.95 13.18 16.52 16.28 22.62 22.36 32.96 32.50 49.77 49.35 79.91
Lens type Zoom Lens
Projection lens Model No. ET-C1U100 ET-C1W300
Standard zoom lens /
ET-C1W400 / ET-C1W500 /
ET-C1S600 / ET-C1T700
Projected image size
Height position (H)
Diagonal (SD)
Height
(SH)
Width
(SW)
1.78 (70") 0.691 1.638 ― -0.17 - 0.86 -0.27 - 0.96
2.03 (80") 0.790 1.872 ― -0.19 - 0.98 -0.31 - 1.10
2.29 (90") 0.889 2.106 ― -0.21 - 1.10 -0.35 - 1.23
2.54 (100") 0.987 2.340 -0.24 - 1.23 -0.24 - 1.23 -0.38 - 1.37
3.05 (120") 1.185 2.808 -0.29 - 1.47 -0.29 - 1.47 -0.46 - 1.65
3.81 (150") 1.481 3.510 -0.36 - 1.84 -0.36 - 1.84 -0.58 - 2.06
5.08 (200") 1.975 4.681 -0.48 - 2.45 -0.48 - 2.45 -0.77 - 2.74
6.35 (250") 2.468 5.851 -0.59 - 3.06 -0.59 - 3.06 -0.96 - 3.43
7.62 (300") 2.962 7.021 -0.71 - 3.68 -0.71 - 3.68 -1.15 - 4.11
8.89 (350") 3.456 8.191 -0.83 - 4.29 -0.83 - 4.29 -1.34 - 4.80
10.16 (400") 3.949 9.361 -0.95 - 4.90 -0.95 - 4.90 -1.54 - 5.49
12.70 (500") 4.936 11.701 -1.19 - 6.13 -1.19 - 6.13 -1.92 - 6.86
15.24 (600") 5.924 14.042 -1.43 - 7.35 -1.43 - 7.35 -2.30 - 8.23
17.78 (700") 6.911 16.382 -1.66 - 8.58 -1.66 - 8.58 -2.69 - 9.60
20.32 (800") 7.898 18.722 -1.90 - 9.80 -1.90 - 9.80 -3.07 - 10.97
22.86 (900") 8.886 21.062 -2.14 - 11.03 -2.14 - 11.03 -3.46 - 12.34
25.40 (1000") 9.873 23.403 -2.38 - 12.25 -2.38 - 12.25 -3.84 - 13.71
*1 The throw ratio is based on the value during projection with the projected image size of 2.54 m (100").
However, the throw ratio for ET-C1U100 is based on the value during projection with the projected image size of 3.81 m (150").
*2 For ET-C1U100, ne text and images may not be displayed clearly during projection with the projected image size over 15.24 m (600").
