Chapter 4 Settings — [DISPLAY OPTION] menu
ENGLISH - 139
[DISPLAY OPTION] menu
On the menu screen, select [DISPLAY OPTION] from the main menu, and select an item from the sub-
menu.
Refer to “Navigating through the menu” (x page 102) for the operation of the menu screen.
[COLOR MATCHING]
Correct the color difference between projectors when using multiple projectors simultaneously.
Adjusting the color matching as desired
1) Press as to select [COLOR MATCHING].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] Color matching adjustment is not carried out.
[3COLORS] Adjusts the three colors [RED], [GREEN], or [BLUE].
[7COLORS] Adjusts the seven colors [RED], [GREEN], [BLUE], [CYAN], [MAGENTA], [YELLOW], or [WHITE].
[MEASURED]
Refer to “Adjusting the color matching using a colorimeter” (x page 139) for details about this mode.
3) Select [3COLORS] or [7COLORS].
4) Press the <ENTER> button.
f The [3COLORS] or [7COLORS] screen is displayed.
5) Press as to select [RED], [GREEN], or [BLUE] ([RED], [GREEN], [BLUE], [CYAN], [MAGENTA],
[YELLOW], or [WHITE] when [7COLORS] is selected).
f The adjustment condition can be reset by selecting [RESET]. For details regarding [RESET], refer to
“Resetting the adjustment condition of the color matching” (x page 140).
6) Press the <ENTER> button.
f The [3COLORS:RED], [3COLORS:GREEN], or [3COLORS:BLUE] screen is displayed.
When [7COLORS] is selected, the [7COLORS:RED], [7COLORS:GREEN], [7COLORS:BLUE],
[7COLORS:CYAN], [7COLORS:MAGENTA], [7COLORS:YELLOW], or [7COLORS:WHITE] screen is
displayed.
f By setting [AUTO TESTPATTERN] to [ON], the test pattern for the selected color is displayed.
7) Press as to select [RED], [GREEN], or [BLUE].
8) Press qw to adjust.
Note
f Operation when correcting the adjustment color
When the correction color same as the adjustment color is changed: The luminance of the adjustment color changes.
When correction color red is changed: Red is added to or subtracted from the adjustment color.
When correction color green is changed: Green is added to or subtracted from the adjustment color.
When correction color blue is changed: Blue is added to or subtracted from the adjustment color.
f Since advanced skills are necessary for the adjustment, this adjustment should be carried out by a person who is familiar with the projector
or by a service person.
f When [RESET] is set to [PICTURE MODE] and the <DEFAULT> button on the remote control is pressed, the selected adjustment item will
return to the value of factory default for the current picture mode.
f When [RESET] is set to [NATIVE], pressing the <DEFAULT> button on the remote control will return the value to uncorrected value.
f When [COLOR MATCHING] is set to other than [OFF], [COLOR TEMPERATURE] is xed to [USER1].
Adjusting the color matching using a colorimeter
Use a colorimeter that can measure chromaticity coordinates and luminance to change the colors [RED],
[GREEN], [BLUE], [CYAN], [MAGENTA], [YELLOW], or [WHITE] to desired colors.
1) Press as to select [COLOR MATCHING].
2) Press qw to select [MEASURED].
To Next Page
