Panasonic PT-RQ25K Series

2 - ENGLISH
Contents
Contents
Read this rst! 5
Chapter 1 Preparation
Precautions for use 21
Intended use of the product
21
Installation and handling of the laser product
(for USA and Canada)
21
Cautions when transporting
21
Cautions when installing
21
Cautions when setting up the projector
23
Security
25
Notes regarding the wireless LAN
25
QUAD PIXEL DRIVE
26
Slot
26
DIGITAL LINK
26
Art-Net
26
Application software supported by the projector
27
Storing
27
Disposal
27
Cautions on use
27
Accessories
29
Optional accessories
30
About your projector
32
Remote control
32
Projector body
34
Names and functions of the Function Board
(optional)
37
Preparing the remote control
39
Inserting and removing the batteries
39
When using the multiple projectors
39
Connecting the remote control to the projector
with a cable
40
Chapter 2 Getting Started
Setting up 42
Usable outlet
42
Installation mode
42
Parts for installation (optional)
43
Projected image and throw distance
44
Adjusting adjustable feet
57
Attaching/removing the projection lens
58
Attaching the projection lens
59
Removing the projection lens
60
Installing the Function Board 61
Before installing or removing the Function
Board
61
For Intel
®
SDM-S specication Function Board 62
Installing the Function Board
63
Removing the Function Board
63
Connecting
64
Before connecting
64
Connecting example: AV equipment
65
Connecting example: Computers
66
Connecting example using DIGITAL LINK
67
Connecting example when using the
contrast synchronization function/shutter
synchronization function
69
Chapter 3 Basic Operations
Switching on/off the projector 72
Connecting the power cord
72
Power indicator
73
Switching on the projector
74
When the initial setting screen is displayed
75
When the administrator account setting screen
is displayed
81
Making adjustments and selections
82
Switching off the projector
83
Projecting
84
Selecting the input signal
84
Adjusting the focus, zoom, and lens shift
86
Adjusting the focus balance
87
Conrming the lens type
89
Executing the lens calibration
89
Moving the projection lens to the home position
91
Lens shift range
92
Adjusting the lens mounter when the focus is
unbalanced
94
Using the USB memory
96
Notes on use
96
USB memory that can be used with the
projector
96
Attaching the USB memory
96
Removing the USB memory
96
Operating with the remote control
97
Using the shutter function
97
Using the on-screen display function
97
Switching the image aspect ratio
98
Using the function button
98
Displaying test patterns
98
Using the status function
99
Setting ID number of the remote control
99
