Chapter 4 Settings — [DISPLAY OPTION] menu
150 - ENGLISH
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [4K DIVISION].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically selects [SQUARE] or [INTERLEAVE].
[SQUARE] Fixes the transmission method to Square Division.
[INTERLEAVE] Fixes the transmission method to 2-Sample Interleave Division.
Setting [SYSTEM SELECTOR] in [SLOT IN] (SDI input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SYSTEM SELECTOR].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically selects [RGB], [YP
B
P
R
4:4:4], or [YP
B
P
R
4:2:2].
[RGB] Fixes to [RGB].
[YP
B
P
R
4:4:4] Fixes to [YP
B
P
R
4:4:4].
[YP
B
P
R
4:2:2] Fixes to [YP
B
P
R
4:2:2].
Setting [BIT DEPTH] in [SLOT IN] (SDI input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [BIT DEPTH].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically selects [12-bit] or [10-bit].
[12-bit] Fixes to [12-bit].
[10-bit] Fixes to [10-bit].
When the optional DIGITAL LINK Terminal Board (Model No.: TY-SB01DL) is installed
Setting [SIGNAL LEVEL] in [SLOT IN] (DIGITAL LINK input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SIGNAL LEVEL].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically sets the signal level.
[64-940]
Select this item when the signal output from the HDMI terminal of the external device (such as a Blu-
ray disc player) is input to the <DIGITAL LINK IN/LAN> terminal via a twisted-pair-cable transmitter.
