Panasonic PT-RQ25K Series

Chapter 7 Appendix — Specications
328 - ENGLISH
Signal type
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
Compatible signal
Horizontal
(kHz)
Vertical
(Hz)
HDMI DisplayPort
DIGITAL
LINK
*1
C 640 x 480/60 640 x 480 31.5 59.9 25.2
l l l
1024 x 768/50 1 024 x 768 39.6 50.0 51.9
l l l
1024 x 768/60 1 024 x 768 48.4 60.0 65.0
l l l
1280 x 800/50 1 280 x 800 41.3 50.0 68.0
l l l
1280 x 800/60 1 280 x 800 49.7 59.8 83.5
l l l
1280 x 1024/50 1 280 x 1 024 52.4 50.0 88.0
l
―
l
1280 x 1024/60 1 280 x 1 024 64.0 60.0 108.0
l
―
l
1366 x 768/50 1 366 x 768 39.6 49.9 69.0
l
―
l
1366 x 768/60 1 366 x 768 47.7 59.8 85.5
l
―
l
1400 x 1050/50 1 400 x 1 050 54.1 50.0 99.9
l l l
1400 x 1050/60 1 400 x 1 050 65.2 60.0 122.6
l l l
1440 x 900/50 1 440 x 900 46.3 49.9 86.8
l
―
l
1440 x 900/60 1 440 x 900 55.9 59.9 106.5
l
―
l
1600 x 900/50 1 600 x 900 46.4 49.9 96.5
l l l
1600 x 900/60 1 600 x 900 55.9 60.0 119.0
l l l
1600 x 1200/50 1 600 x 1 200 61.8 49.9 131.5
l l l
1600 x 1200/60 1 600 x 1 200 75.0 60.0 162.0
l l l
1680 x 1050/50 1 680 x 1 050 54.1 50.0 119.5
l
―
l
1680 x 1050/60 1 680 x 1 050 65.3 60.0 146.3
l
―
l
1920 x 1200/50 1 920 x 1 200 61.8 49.9 158.3
l l l
1920 x 1200/60RB 1 920 x 1 200
*4
74.0 60.0 154.0
l l l
2560 x 1440/50 2 560 x 1 440 74.1 50.0 256.3
l l l
2560 x 1440/60 2 560 x 1 440
*4
88.8 60.0 241.5
l l l
2560 x 1600/50 2 560 x 1 600 82.4 50.0 286.0
l l l
2560 x 1600/60 2 560 x 1 600
*4
98.7 60.0 268.5
l l l
3840 x 2400/30 3 840 x 2 400
*4
73.0 30.0 286.2
l l l
3840 x 2400/50 3 840 x 2 400
*4
122.9 50.0 481.6
l l
―
3840 x 2400/60 3 840 x 2 400
*4
148.1 60.0 592.5
l l
―
*1 This is supported when the optional DIGITAL LINK Terminal Board (Model No.: TY-SB01DL) is installed in the slot.
*2 The signal with 1/1.001x vertical scanning frequency is also supported.
*3 YP
B
P
R
4:2:0 format only
*4 VESA CVT-RB (Reduced Blanking)-compliant
Note
f A signal with a different resolution, including SDI signal, is displayed converted to the number of display dots. The number of display dots is
as follows.
g 3 840 x 2 400: When using PT-RQ25K/PT-RQ18K and [QUAD PIXEL DRIVE] is set to [ON]
g 1 920 x 1 200: When using PT-RQ25K/PT-RQ18K and [QUAD PIXEL DRIVE] is set to [OFF]
g 1 920 x 1 200: When using PT-RZ24K/PT-RZ17K
f The “i” at the end of the resolution indicates an interlaced signal.
f When interlaced signals are connected, ickering may occur on the projected image.
f When using PT-RQ25K/PT-RQ18K and the image of 720/120p or 1080/120p is displayed, the [CUSTOM MASKING] setting of [BLANKING]
will be disabled.
f When the DIGITAL LINK connection is made with the long-reach communication method, the signal that the projector can receive is up to
1080/60p (1 920 x 1 080 dots, dot clock frequency 148.5 MHz).
f Even if it is the signal listed in the list of compatible signals, it may not be displayed by the projector if the image signal is recorded in a
special format.
