Digiplex EVO • Programming Guide
Version 7.11
EN50131 Compliancy | 77
Table 83: Description of Section
[3033]
Section Option Description OFF ON
Section [3033]
System Options 3
1 Multiple actions in user menu Disabled
Enabled
2 User code length Fixed
Flexible
3 User code length (if option 2 is OFF)* 4 digits
6 digits
4Power save mode
Disabled Enabled
5 Bypass not displayed if system is armed
Disabled Enabled
6 Trouble latch
Disabled Enabled
7 EOL resistor on hardwire zones
Disabled Enabled
8Zone doubling (ATZ) Disabled
Enabled
*All numbers from 000000 to 999999 are valid giving a total of 1,000,000 different possible combinations.
Table 84: Description of Section [3034]
Section Option Description OFF ON
Section [3034]
System Options 4
1
Wireless transmitter supervision
Refer to Table 85 on
page 77
Refer to Table 85 on
page 77
2
3
Generate supervision failure if detected on a bypass
wireless zone
Yes
No
4
Restrict arming on a wireless transmitter supervision
failure
Disabled
Enabled
5
Zone and module tamper recognition options
Refer to Table 86 on
page 77
Refer to Table 86 on
page 77
6
7 Generate tamper if detected on bypass zone
Yes No
8 Restrict arming on tamper trouble
Disabled Enabled
Table 85: Wireless Transmitter Supervision (options 1 and 2 for Section [3034] above)
Option
Description
1 2
OFF OFF Disabled (default)
OFF ON Generates trouble only (when armed or disarmed)
ON OFF
When armed: alarm
When disarmed: generates trouble only
ON ON
When armed: alarm
When disarmed: generates audible alarm
Table 86: Zone and Module Tamper Recognition (options 5 and 6 for Section [3034])
Option
Description
5 6
OFF OFF Disabled
OFF ON Generates trouble only (when armed or disarmed)
ON OFF
When armed: alarm (default)
When disarmed: generates trouble only
ON ON
When armed: alarm
When disarmed: generates audible alarm
Table 87: Description of Section [3035]
Section Option Description OFF ON
Section [3035]
System Options 5
1 Restrict arming on AC failure Disabled
Enabled
2 Restrict arming on battery failure Disabled
Enabled
3 Restrict arming on bell or auxiliary failure
Disabled Enabled
4 Restrict arming on TLM failure
Disabled Enabled
5 Restrict arming on module troubles
Disabled Enabled
6 Account number transmission Partition #
Tel #
7 Transmit zone status on serial port* Disabled
Enabled
8 Serial port baud rate
38400 57600
*This option is used by certain event monitoring software, such as Hyperterminal. With BabyWare and printers, it is always being transmitted.
