A N A F I U S A
11
© 2023 Parrot Drones SAS. All Rights Reserved.
Technical specifications
DRONE
Mass: 500 g (1.1 lb)
Maximum take-off mass (MTOM): 644 g (1.4 lb)
Maximum transmission range: 4 km (2.5 mi) with the enclosed
Parrot Skycontroller
Maximum flight time: 32 minutes
Maximum horizontal speed: 14.7 m/s (32.9 mph)
Maximum ascent speed: 4 m/s (8.9 mph)
Maximum descent speed: 3 m/s (6.7 mph)
Maximum wind resistance: 14.7 m/s (32.9mph)
Maximum propeller speed: 11,000 rpm
Sound power level at 1m (3.3 ft): 84 dB
Service ceiling: 5,000 m above MSL (Mean Sea Level)
User defined geofencing
Operating temperature: -36°C (-33°F) to +50°C (122°F)
No take-off temperature limitation - if battery temperature is
maintained between +5°C (+41°F) and +70°C (+158°F)
IP53: Rain and dust resistant
Maximum static thrust: 12.92 N
Thrust to weight ratio: 2.63
No NFZ (no-fly zone) limitation
Takes off from / lands in the hand of the operator
Manage your data privately between drone and device OR
share anonymous data on secured European servers
DIMENSIONS
Size folded: 252 x 104 x 84 mm (9.9 x 4.1 x 3.3”)
Size unfolded: 282 x 373 x 82 mm (11.1 x 14.7 x 3.2”)
SENSORS
Satellite navigation: GPS, GLONASS & GALILEO
Barometer and magnetometer
Vertical camera and ultra-sonar
2 x 6-axis IMU
2 x 3-axis accelerometers
2 x 3-axis gyroscopes
EO IMAGE CHAIN
2 Sensors: 1/2.4’’
Digital zoom: 32x
Electronic shutter speed: 1 s to 1/10,000 s
ISO range: 100-3200
Video resolution: 4k/FHD/HD
Video format: MP4 (H.264)
Photo resolution:
o Wide: 21 MP (84° FOV);
o Rectilinear: up to 16 MP (up to 75.5° FOV)
Photo formats: JPEG, DNG (Digital NeGative RAW)
IR IMAGE CHAIN
Sensor: FLIR BOSON
320x256 resolution
-40°C (-40°F) to +150°C (+302°F) temperature range
Thermal sensitivity: <60 mK
Measured IR wavelength range: 7.5 to 13 micrometers
Photo format: JPEG
Video format: MP4 (H264)
Video recording resolution: 1280x720, 9 fps
IMAGE STABILIZATION
3-camera IR/EO stabilized gimbal:
o Hybrid: 3-axis
o Mechanical: 2-axis roll / pitch
o Electronics (EIS): 3-axis yaw / roll / pitch
Controllable gimbal tilt range: -90° to +90°
FAST-CHARGING SMART BATTERY
Type: High density LiPo
Capacity: 3,400 mAh (3 x 4.4 V cells)
Battery life: 32 minutes
Charging port: USB-C
Charges fully in 2h with a USB-PD (Power Delivery) charger not
included in the pack
Charges fully in 3h20 with the fast-charging port of the provided
charger
Mass: 195 g (0.4 lb)
Voltage: 11.55 V
Max charging power: 30 W
PARROT SKYCONTROLLER 3
Folded size: 94 x 152 x 72 mm (3.7 x 6.0
x 2.8”)
Unfolded size: 153 x 152 x 116 mm (6.0
x 6.0 x 4.6”)
Mass: 283 g (0.6 lb)
Transmission system: Wi-Fi 802.11a/b/g/n (Wi-Fi beacon)
Operating frequencies: 2.4 GHz, 5.8 GHz, UNII-1 & UNII-3
Direct video stream resolution: 720p
Battery capacity: 2500 mAh (3.6 V)
Battery life: Charges fully in 1h10 (with a 1.85 A charger).
Discharges in 2h30 (with Android device) / 5h30 (with iOS device)
Compatible mobile devices: Screen size up to 6.5
USB ports: USB-C (charge), USB-A (connection)
PARROT SKYCONTROLLER 4
Size without terminal: 238 x 147 x 55 mm (9.4 x 5.8 x 2.2”)
Maximum size: 315 x 147 x 55 mm (12.4 x 5.8 x 2.2”)
Mass: 610 g (1.34 lb)
Transmission system: Wi-Fi 802.11a/b/ g/n (Wi-Fi beacon)
Operating frequencies: 2.4 GHz, UNII-1 & UNII-3
Direct video stream resolution: 720p
Battery capacity: 3,350 mAh (7.2 V)
Battery life: Charges fully in 3h45 for up to 6h use (varies
according to device used and state of charge)
Compatible mobile devices: Screen size up to 8"
Charges smartphones and tablets
USB ports: 2xUSB-C (charging and connecting)
Micro-HDMI port
Dust resistant (IP5X)
