EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
IntelliChlor
®
Salt Chlorine Generator - (optional)
TheoptionalIntelliChlorSaltChlorineGeneratorsystemallowstheEasyTouch
PL4/PSL4ControlSystemsystemtoautomaticallycontrolwatersanitizationby
usingalowconcentrationofsalt(sodiumchloride)inthepoolandspawater.
IntelliChlorautomaticallyconvertsthesaltintofreechlorinewhicheliminate
bacteriaandalgaeinthepoolandspawater.Thechlorinewillthenrevertbackto
sodiumchlorideafterkillingthebacteria.Theoutcomeofthiscontinuouscycle,
practicallyeliminatestheneedtousesanitizingchemicalsinthepool/spawater.
IntelliChlormodelIC20(P/N520554/520556)isdesignedforswimmingpoolsupto
20,000U.S.gallons(75,000liters).ModelIC40(P/N520555/520556)isdesigned
forswimmingpoolsupto40,000U.S.gallons(151,000liters).
IntelliChem
®
Chemical Controller (optional)
TheoptionalIntelliChem
®
ControllerisapHandORPsensingdevicethat
dispensescorrectamountofchlorineorbromine,muriaticacidorCO2gas.
IntelliChemprovidescontinualanalysisofyourswimmingpoolwatersanitation
andpHlevels,providingreal-timestatusinformationtodispensetheproper
amountofmuriaticacid(pHreducer)andchlorineorbromineforthecorrect
sanitizationandpHbalance.IntelliChemControlleroperateswithorwithouta
saltchlorinegeneratortoprovideaself-replenishingsupplyofchlorinegenerated
fromsalt.IntelliChemControllercanalsoconnecttocarbondioxide(CO2)liquid
gastankstolowerpHinyourswimmingpoolwater.WhenCO2dissolvesinto
wateritproducesweakneutralbicarbonatesaltswhichreducespH.CO2is
environmentallyfriendlyandproducesnosecondarypollutionintothetreated
waterbysaltssuchaschloridesorsulfates.IntelliChemalsosupportsIntelliChlor
®
SaltChlorineGeneratortohelpmanageyourpoolwatersanitizerlevels.
Indoor Control Panel (optional)
TheEasyTouchPL4/PSL4IndoorControlPanelprovidesyouwithonetouch
automaticcontrolforallofyourpoolandspadailyoperationsfrominsideyour
home.TheindoorcontrolpanelisconnectedtothePowerCenterenclosure.
iS4 Spa-Side Remote (optional)
TheiS4Spa-Sideremotecontrollerisadouble-insulated,waterproofdevice
thatisUL(1563)listedforinstallationatthewater’sedge.Installedabove
thewaterlineofthespawall,orinthedeckwithinarm’sreachofaspa
occupant.TheiS4cancontrolfourcircuitsfromthe
spalocation.Usedforactivatingspacirculationandanythreeauxiliary
piecesofequipment(suchaslights,jetpump,airblower,etc.).Thered
statusLEDindicatorglowssteadywheninSpamodeandasheswhilethe
spaisheating.FormoreaboutassigningcircuitstotheiS4buttons,refer
to“SettingsMenu:iS4Spa-SideRemotecontroller,”onpage50.Thereare
twoinstallationchoicesasshown.
QuickTouch
®
II Wireless Controller (optional)
TheoptionalhandheldQuickTouch
®
IIWirelessControllercancontroluptofour
pool/spacircuits.Eachofthefourfunctionsontheremotehasanonandanoff
button.Formoreinformation,seepage50.
QuickTouchIIWirelessRemote
(P/N521245)
Wireless Control Panel (optional)
TheEasyTouchPL4/PSL4ControlSystemWirelessControllerprovidescomplete
controlofpoolandspaoperationsfrominsideyouhomeoroutsidearoundyour
poolarea.Formoreinformation,seepage55and65.
EasyTouch
®
PL4/PSL4 Control System Accessories
IntelliChlorSaltChlorineGenerator
IntelliChemChemicalController
iS4Spa-SideRemote
(P/N521885)Optional
