EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
Settings Menu: Custom Names
Therearenearly100circuitnamesavailabletochoosefrom.Ifyoucannotndonetotyourapplicationyou
cancreateupto10customnames.Eachnamecanbeupto11alphanumericcharacters.Afteracustom
nameissaved,itisthenavailableforselectionintheSchedules,2-SpeedPump,iS4andQuickTouch
Controllermenus.
Custom Name
Toassignacustomcircuitname:
MENUsSETTINGSsCIRCUIT NAMESwCUSTOM NAMES
Up/Down buttons: Selectacustomcircuitnamenumber(1-10).Youcancreateupto
10customcircuitnames.
Right button: Movetocustomcircuitnamesetting.
Up/Down/Right buttons: Enterthecustomcircuitname(11charactersmaximum).
PresstheMenubuttontosavethesettingsandtoreturntotheSettingsmenu
options.Pressthebuttonagaintoreturntothemainmenuoptionsorpressagainto
returntothemainscreen.
Settings Menu: Valves
ThisfeatureletsyouassignacircuittoValveAorB.TheEasyTouchPL4/PSL4ControlSystemcandrivetwo
auxiliaryvalveactuators(AandB)forapplicationssuchassolarheatingandwaterfeatures.Byassigning
AUXcircuitstocontrolvalveactuators,youcanconserveauxiliarycircuitsforhighvoltagerelaysfor
controllingpumpsandlights.
Valve A:ResidesontheEasyTouchPL4/PSL4ControlSystemmaincircuitboard.Ifsolarheatingissetup
andisnotconguredasaheatpump,thenValveAisdedicatedforcontrollingthesolarheatingvalve
actuator.Solarisenabledinthe“Solar”menu.TheValveAselectionwilldisplay“USEDSOLAR.”
Valve B:Residesonthemaincircuitboard.Canbeconguredtobecontrolledbyanycircuit.
Valves
ToassignacircuittoValveAandValveB:
MENUsSETTINGSsVALVESwSETUP VALVES
Up/Down buttons: SelectacircuittoassigntoVALVE A.Thegenericcircuitnames
are:Thegenericcircuitsnamesare:NONE,SPA,POOL,AUX1-3
FEATURE1-2,andHEATER.UsetheSolarbuttontoswitchthecircuitonandoff
(seepage5).SelectingNONEdoesnotassignacircuit.
Right button: MovetoValveBsetting.
Up/Down buttons: SelectacircuittoassigntoValveB.Seeaboveforthegeneric
circuitsnames.
PresstheMenubuttontosavethesettingsandtoreturntotheSettingsmenu
options.Pressthebuttonagaintoreturntothemainmenuoptionsorpressagainto
returntothemainscreen.
Cstm Name 1/10
[USERNAME-01]




Set Valves
A: [CLEANER ]
B: [FOUNTAIN ]


Set Valves
A: [USED SOLAR]
B: [FEATURE 1 ]
