Pentair EASYTOUCH PL4 User Manual

EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
  3
EasyTouch
®
PL4/PSL4 Control System Power Center
•Pumps
Filter,Cleaner,SpaJet,
 1.5HP120VAC
 3HP277VAC
 20FLA/120LRA,
120VAC
 17FLA/102LRA,
277VAC
• Relays
25AMP,277VAC
•Pool/Spa Lights
1.5KW120VAC
Tungsten
4.8KW240VAC
Tungsten
20AMP,277VACBallast
• Pool/Spa Valve
Suctionandreturn.
24VACvalveactuator,
sharedequipmentonly
• Auxiliary Valves
(Qty.2)AandB
• Heater
Gasorelectric
• Heat Pump
(UltraTemp
®
)
Heatingorcooling
• IntelliFlo
®
Pumps:
VS Pump P/N011018
TemperatureSensors
(Water,AirandSolar)
ElectricHeater-Connects
toplugJ16onEasyTouch
PL4/PSL4ControlSystem
circuitboard
IndoorControlPanel
(3AUXcircuits)
(P/N522465)Optional
LowVoltage(DC)
circuitbreakers
EasyTouchPL4/PSL4ControlSystem
OutdoorControlPanel(notshown)
ConnectstoOutdoorControl
PanelRS-485COMport,located
onEasyTouchPL4/PSL4Control
SystemPowerCentermaincircuit
board
Wireless Controller
(3 AUX circuits)
(P/N 522464) Optional
• IntelliChlor
®
SaltChlorineGenerator(with
separatePowerCenter):
• IC20P/N520554520556
• IC40P/N520555/520556(seepage26)
• IntelliChem
®
Controller:P/N521357(no
pump),P/N521356(onepump),P/N
521355(twopump).Seepage39.
QuickTouch
®
II
WirelessRemote
(P/N521245)Optional
iS4Spa-SideRemote
(P/N521885)Optional
Pantone Colors:
429 Buttons
431 Background
SHOWN WITH 1
SERIAL COM PORT
EXPANSION
CIRCUIT BOARD
(OPTION)
P/N 520818
EasyTouchPL4/PSL4ControlSystemPowerCenter
(Frontpanelandoutdoorcontrolpanelnotshown)
QuickTouch
®
II
WirelessController
TransceiverAntenna
