Page #53 background imageLoading...
Page #53 background image
EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
45
Preset Circuit Functions
Generic
No special Logic. Simple On/Off control of a circuit with all the programmable
capabilities.
Master Spa
Works with automatic pool cleaner pumps or cleaner valve actuator. It does the
following:
- Forces the filter pump on 5 minutes before the cleaner pump switches on.
- Switch the cleaner off when the spa is on.
- Switch the cleaner off for 5 minutes when the solar heating begins.
Master Pool
Works
with automatic
pool cleaner pumps or cleaner valve actuator. It does the
following:
- Forces the filter pump on 5 minutes before the cleaner pump switches on.
- Switch the cleaner off when the spa is on.
- Switch the cleaner off for 5 minutes when the solar heating begins.
Master Cleaner
Works with automatic pool cleaner pumps or cleaner valve actuator. It does the
following:
- Forces the filter pump on 5
minutes before the cleaner pump switches on.
-
Switch the cleaner off when the spa is on.
- Switch the cleaner off for 5 minutes when the solar heating begins.
Light
Allows special lighting features to work, such as ALL lights on or ALL lights off.
SAM Light
Activates special color lighting programs on other screens on the Indoor Control Panel
when used with SAM pool lights. For example, you can have AL
L lights on or ALL
l
ights off.
SAL Light
Activates special color lighting programs on other screens on the Indoor Control Panel
when used with SAL spa lights. For example, you can have ALL lights on or ALL lights
off.
Photon Generator
Photon Generator® light source allows Pentair Fiberworks fiber optic bulb be operated
by the Lights menu features Sync, Rotate, ALL ON and ALL OFF when used with SAM
and SAL
lighting.
Col
or Wheel
Activates special color lighting programs on other screens on the Indoor Control Panel
when used with Pentair Fiberworks. For example, you can have ALL lights on or ALL
lights off.
Spillway
For pool/spa combinations where the spa is raised above the pool. This setting moves
the return valve so that the filter pump pulls the water from the pool and returns it to
the spa, creating a water fall effect
. Automatic pool cleaners are turned off when this
feature is turned on.
Floor Cleaner
This setting moves a 3-way valve every 20 minutes alternating flow between 2 cleaner
system valves that feed the pop-up heads.
IntelliBrite
Activate an Intellibrite LED light.
MagicStream
Activate a MagicStream laminar.
