42
EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
Settings Menu: Circuit Names
Labeling Circuit Buttons in the EasyTouch
®
PL4/PSL4 Control System Power Center
EasyTouchPL4/PSL4ControlSystemisfactoryconguredtodisplayeachoutputcircuitbyitsgenericname
(e.g.AUX1,AUX2,AUX3).Thesegenericcircuitauxiliarynamescanbeassignedanewnameswhichare
moredescriptiveoftheequipmentbeingcontrolled.Thismakesitmucheasiertooperateallofthepool,spa
andlightingequipmentwithouthavingtomemorizewhateachoutputcontrols.
Forcircuitidentication,adhesivebackedcircuitnamelabelsareprovidedforplacementnexttoeachauxiliary
controlpanelbutton.Usethewrittenlistofcircuitnames(buttons)thatyoumadewhilesettingupthePower
Center.Identifywhatyoulabeledcircuitbutton1,button2etc.Thecircuitnamesyouassignshouldmatchthe
labelsyouputonthePowerCentercontrolpanelbuttonsand/ortheoptionalIndoorControlPanelbuttons.
Notethatexamplesshownbelowusethefactorysetgenericoutputnamesdisplayedinthecontrolsystem
controlpanelmenus.
Circuit Names
Toassigncircuitnames:
MENUsSETTINGSsCIRCUIT NAMESwCIRCUIT NAMES
Up/Down buttons: Selectthecircuitnumber1/7.PresstheUp buttontwotimesto
selectAUX1.The generic circuits names are: Spa (1/7), Pool (2/7), Aux 1-3 (3-
5/7), Ft 1-2 (6-7/7). Thecircuitnumber1/7correspondstoitsassignedcircuitname.
Thisnamecanbechangedtosuitthefunction.
Right button: Movetosystempresetcircuitnamesanduserdenedcustomcircuit
names.
Up/Down buttons: Scrollthroughthelistofalphabeticalprogrammednames.Ifyou
cannotndanametomatchyourcircuit,youcancreateyourowncustomname
(seepage48).Repeatforallthecircuitbuttonsthatyouwishtoassignnamesto.For
acompletelistofsystemcircuitnames,seepage43.
PresstheMenubuttontosavethesettingsandtoreturntotheSettingsmenu
options.Pressthebuttonagaintoreturntothemainmenuoptionsorpressagainto
returntothemainscreen.
Note: After a generic circuit name is changed and saved, the new name is displayed
in the menu settings. You can view the default generic circuit names in the menu
settings before they were changed by enabling “Cir Names. Refer to “Diagnostics: Cir
Names (Off), on page 59.
Hi-Temp/Lo-Temp Controls for Single Body System
ForanEasyTouchPL4ControlSystemsinglebodysystem,youhavetheoptiontocontrolyourpooland
spatemperaturesettingsusingtheValves(V)buttonortheSpa(Hi-Temp)andPool(Lo-Temp)buttononthe
optionalIndoorControlPanel.ChangethecircuitnameSPA to HI-TEMPandPOOL to LO-TEMPsothatthe
displayshowsthecorrecttemperaturecontrolsforyoursinglebodysystem.
Circuit Names
Circuit #: 1/7
Circuit : SPA
[SPA JET ]
