EasyTouch
®
PL4/PSL4 Control System Outdoor Control Panel Operating Modes
TheEasyTouchPL4/PSL4ControlSystemcanruninautomaticmodeormanualmode.Usethe“Mode”button
toswitchthesystemfrom“Auto”mode(normaloperatingmode)to“Service”formanualoperationandservice
purposes.Beforeoperatingthesystem,familiarizeyourselfwiththeLCDstatusmessagesandoperatingbuttons.
AUTO (Automatic): Thesystemisinnormaloperatingmode.
Scheduledprogramswillrunautomatically.
HEATER:Displaystheheatsource(Off, Heater, Solar Prf., Solar)
asspeciedintheHeatermenusettings(seepage30).Whenthe
FilterPump(F)buttonispressedin“Pool”or“Spa”mode,andheat
sourceisenabled(HeaterbuttonLEDon).
POOL (SPA):IndicatesthattheValves(V)buttonisin“Pool”or
“Spa”modeandtheFilterPump(F)buttonhasbeenpressedto
switchonthelterpump.Ifthisdisplaylineisblank,itindicatesno
spaorpoolfunctionisactive.Forasinglebodysystem,Hi-Temp
(Spa)/Lo-Temp(Pool)setsthetemperaturesettings(seepage44)
85° F / 100° F:Displaystheactualspaorpoolwatertemperature
(85°F)andthesetpointtemperature(100°F)assetinthe“Heat”
menu(seepage30).
AIR:Displaystheactualoutsideairtemperature(70°F)asreadby
theairsensorlocatednearthePowerCenter.
Date and Time:Displaysthesystemdayandtimeasspeciedin
the“Clock”menusettings(seepage34).
Valves (V) button: Wheninnormal
operatingmode,thesystemisin“Pool”
modesothatonlythepoolwateris
circulatedthroughthesystem.Pressthe
Valvesbuttontoenable“Spa”modeandto
rotatevalvesandactivatetheFilterpump
(FilterPumpLEDon)automaticallysothat
onlythespawateriscirculatedthroughthe
system.Notethatthelterpumpwillswitch
offwhilethepool/spavalvesarerotating
intoposition. “Fill/Spillway”and“Drain”
modesareusedonlyin“Service”mode.
MENU / BACK button:
Accessthesystemmenu.
Alsousedtosaveandexit
fromacurrentmenuor
sub-menusettings.While
inmenumode,allsystem
controlpanelbuttonsare
disabled.Pressthisbutton
twicetorefreshthedisplay.
AUTO HEATER
SPA 85°F / 100°F
AIR 70°F
MON 09:30 AM
Filter Pump button:
Forspaoperations,pressthe
Valves (V)buttontorotate
valvesinto“Spa”mode,then
presstheFilter (F) button
toactivatethelterpump.
PresstheValvesbuttonto
toggleto“Pool”mode.The
HeaterbuttonLEDwillbeon
ifaheatsourceisenabledin
theHeatmenu.
Left and Right
Button:
Usethesebuttonsto
lowerandraisethe
currentsetpointwater
temperaturelevel.
