Pentair EASYTOUCH PL4 User Manual

26
EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
Setting up lights (Continued)
Modes (Color Set)
The“ColorSet”featureallowsanycombinationofuptothreeIntelliBrite
®
,SAm
®
,SAL
®
,and/orFIBERworks
®
lightingtobepresettospeciccolors.FixedlightcolorsareselectedandactivatedfromtheColorsscreen.
IntelliBrite Light: If the light was not previously on, after selecting the fixed colored light, no illumination will
occur for approximately six (6) seconds followed by the selection. If the light was previously on, after selecting
the colored light, the previously selected color will momentarily illuminate, no illumination will occur for
approximately six (6) seconds followed by the selection.
Colors
Chooseanyoneofthevexedcolorstocreateaspectacularunderwaterlightingeffect.Thexedcolors
are:Blue, Green, Red,WhiteandMagenta.YoucanswitcheachxedcoloredlightonorofffromtheColors
screen.
IntelliBrite Light: If the light was not previously on, after selecting a fixed colored light, no illumination will
occur for up to ten (10) seconds (depending on the selection), then a white light will momentarily illuminate,
followed by the color selection. If the light was previously on, selecting the a color button will momentarily
illuminate the previously selected color before changing to the selected color.
Toselectaxedcolorpress:Menu > Lights > Modes > Colors:
Up/Down buttons: Chooseacolorforthelight.
Right button: SwitchtheselectedcoloredlightON.Toswitchthelightoff,goto 
    themainLightsmenuandselectAll Off,orpresstheAUXbuttonassignedtothe
    light.TheAUXbuttonwillalsoswitchthelighton.
PresstheMenubuttonthreetimestoreturnmainmenu.
Hold/Recall
SelectHoldandRecallfromthe“Modes”or“Color”screentocaptureandsaveauniquecoloreffectandrecall
itatalatertime.Forexample,whilealightshow(RomanceMode)isactive,select“Hold”tosavetheexact
colorsthatarebeingdisplayed,thenlater,torecalltheexactcoloreffect,select“Recall.”
Note: After selecting HoldorRecall, no illumination will occur for up to 10 seconds, then a white light will
momentarily illuminate, followed by the saved color.
All On / All Off (Lights Menu)
SelectAll OnorAll OfffromtheLightsscreentomanuallyswitchalllightsonoroff,includingany
MagicStreamlaminarcircuits.Pressthecontrolpanelauxiliarybutton(AuxX)assignedtoalightcircuitwill
alsoswitchalightonoroff.
Sync
SelectSyncfromthe“Lights”screentosynchronizecolorsforallIntelliBrite,SAm,SALandFIBERworks
colorchanginglights.
WARNING-IntelliBriteLights:Duringtheoff/onswitchingprocess,
beforetheselectedcolorisdisplayed,noilluminationwilloccur.This
operatingmodeisnormalduringtheswitchingprocess.Duringthis
periodthepoolandspawillbedarkandprecautionsshouldbetakento
avoidunforeseenaccidents.Failuretoobservethiswarningmayresultin
seriousinjuryordeathtopoolandspausers.
Blue
Green
Red
White



Green
Red
White
Magenta



Magenta
